Intyon Hot Sale 1/2HP 3/4HP 1HP High Pressure High Flow Jet Pump Centrifugal Pump Qb60 Qb70 Qb80 Manufacturer Supplier Water Pump for Irrigation
Overview 1.Q:Are you a manufactory or trading company?We are water pump manufactory with rich production experience.Welc
Description
- Overview
- Detailed Photos
- Product Description
- Product Parameters
Basic Info.
| Model NO. | QB60 QB70 QB80 |
| Max.Head | 50-80m |
| Max.Capacity | 50-100 L/min |
| Driving Type | Motor |
| Material | Cast Iron |
| Structure | Single-stage Pump |
| Assembly | Booster Pump |
| Power | Electric |
| Start Up | Electric Pump |
| Type | Blade Pump |
| Application | Submersible Pump, Clarified Water Pump, Sewage Pump, Slurry Pump, Oil Transfer Pump, Chemical Pump |
| Industry | Mechanical Pump |
| Media | Clean Water Pump |
| Performance | Automatic Pump |
| Theory | Vortex Pump |
| Volt | 110V 220V 240V |
| Frequency | 50Hz 60Hz |
| Impeller | Brass,Aluminum,Plastic,PPO |
| Silicon Steel | Cold Rolled,Hot Rolled |
| OEM | Yes |
| Colorful Package | Support |
| Casing | Cast Iron, Aluminum,Stainlesss Steel |
| Paint Color | Orange,Green,Blue,Red,Black |
| Bearings | Chinese or Oversea Brand |
| Therminal Protector | Yes |
| Seal | Mechanical Seal |
| MOQ | 500PCS |
| IP Class | IP44 IP54 |
| Shaft | Carbon,Stainless Steel |
| Trans Medium pH | 6-8.5 |
| Transport Package | Carton |
| Specification | 0.37kw 0.55kw 0.75kw |
| Trademark | INTYON |
| Origin | China |
| HS Code | 8413709990 |
| Production Capacity | 60000PCS/Month |
Product Description
1.Q:Are you a manufactory or trading company?We are water pump manufactory with rich production experience.Welcome to visit our factory anytime.2.Q:What's your MOQ?Trial sample order(500pcs) is OK.3.Q:What's your payment terms?T/T,L/C,D/P4.Q:What certificates do you have?CE,ROHS,ISO90015.Q: How about the warranty?A: One year warranty for all pumps.6.Q:What is the delivery time?20-30 days after receiving deposit.7.Q:Can you do OEM brand?Yes,welcome.
Detailed Photos
Product Description
QB series pump Description
-
Water pump features and applications
- Compact size, lightweight.
- Easy to install, easy to operate.
- Easy to maintain.
-
- Widely applicable for households, hotels, and inns.
- Suitable for garden irrigation.
- Can be integrated with solar-powered home water supply systems.
- For luxurious households, can be paired with controllers for enhanced usage.
This compact and lightweight water pump is easy to install, operate, and maintain. It finds wide application in households, hotels, inns, and garden irrigation. Additionally, it can be integrated with solar-powered home water supply systems and, for luxurious households, paired with controllers for enhanced functionality.
Component&Construction Pump body: Cast iron, 304 stainless steel inserts,Aluminum Pump support: Cast iron, 304 stainless steel inserts,Aluminum Motor housing: Aluminum/Cast iron Impeller: Brass/Aluminum/PPO Motor shaft: Carbon steel/Stainless steel Bearing: 6201(0.25kW-0.37kW) 6202(0.55kW-0.75kW)
Electric Motor Electric pump speed:(n=2850r.p.m) Insulation :Class F Protection:IP44 Continuous service:S1 Thermal protector Single-phase:110V,115V,220V,230V,240V,50Hz,60Hz
Operating conditions The temperature of pumping liquid does not exceed 100 ºC The ambient temperature does not exceed 40 ºC The maximum suction distance is 9 M.
Product Parameters
| MODEL | POWER | Max.Q. | Max.H | Max.Suc. | Inlet/Outlet | G.W. | Carton size | Qty/20GP | ||
| kw | hp | L/Min | m | m | inch | kg | pcs/carton | cm | pcs | |
| QB60 | 0.37 | 1/2 | 35 | 35 | 9 | 1"×1" | 5.5 | 6 | 43*29*35 | 4100 |
| QB70 | 0.55 | 3/4 | 45 | 48 | 9 | 1"×1" | 9 | 2 | 37*34*22 | 2100 |
| QB80 | 0.75 | 1 | 52 | 60 | 9 | 1"×1" | 10 | 2 | 37*34*22 | 2100 |
