Silent Heavy Duty 400A Engine Driven MMA Stick DC Welder 300AMP Diesel Welding Machine
Overview Package Size1820.00cm * 940.00cm * 1080.00cm Package Gross Weight810.000kg About this item(SCD500)Solving outdo
Description
- Overview
- Product Description
- Product Parameters
- Company Profile
Basic Info.
| Model NO. | SCD500 |
| Type | Self-Starting Diesel Generator |
| Installation Method | Fixed |
| Stroke | Four Stroke |
| Cooling Method | Water Cooling |
| Output Type | AC Three Phase |
| Speed | Speed |
| Conditions of Use | Land Use |
| Usage | Common Units, Standby Unit, Emergency Crew |
| Landuse Type of Unit | Low Noise |
| Excitation Mode | AC Rotating Exciter |
| Machine Type | Weleing Workstaion |
| Rated Power(W) | 25000 |
| Max. Power(W) | 27500 |
| Starting System | Recoil/E-Start |
| Fuel Tank | 85L |
| No-Load Voltage | 76 |
| V-a Cure | Drooping/Flat |
| Current Range(a) | 30A-300A |
| Weling Processes | TIG/Stick/Fcaw |
| Fuel Consumption(L/H) | 6.2L/H |
| Protection Class | IP23 |
| Frequency(Hz) | 50/60 |
| Warning Type | Wate Temperature/Oil Pressure /Battery Charge |
| Net Weight(Kg) | 750 |
| Certification | EU V / CE |
| Transport Package | Each One in a Carton with Pallet |
| Specification | 1820*940*1080 |
| Trademark | Cameo/Senci |
| Origin | Chongqing, China |
| HS Code | 85022000 |
| Production Capacity | 500000pieces/Year |
Packaging & Delivery
Package Size1820.00cm * 940.00cm * 1080.00cm Package Gross Weight810.000kgProduct Description
About this item(SCD500)Solving outdoor welding problems. All-in-one diesel engine driven stick welder&AC generatorWelding processes: Mma,Tig,Fcaw,gouging,cellulse welding machine Generator: 27500 peak watts, 25000 running watts; comes with keychain, electric and recoil start; 85L fuel tank with fuel gauge, running time up to 13.5 hours. Rated speed (RPM) 1500/1800/3000. THD: ≤ 5% Welder: 250A/300A rated output current, welding current Range 30-300A; The generator features 3 standard industrial use AC socket. Powered by Adopting well-known brand(yuchai, kubota, yanmar ) engine and brushless AC generator drive, it has an automatic low oil shut-off function and a 3-in-1 digital meter, plug and play. The welding module adopts IGBT inverter power system, suitable for all kinds of pipeline arc welding (low hydrogen welding, cellulose welding, argon arc welding) Accessories include keychain, oil funnel, tool kit and user manual. All CAMEO portable hair welders are functionally tested at the factory and may contain minimal residual oil and/or fuel odor; meet EU V, CE standards; provide 1 year limited service, labor and parts warranty. Applicable Industries:Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Restaurant, Home Use, Retail, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company.
Product Parameters
| welding workstation | |||||||||||
| Image | |||||||||||
| Model | SCD500 | ||||||||||
| WELDING | Dual operation (A & B) | Handle A | Handle B | ||||||||
| Welding Processes | Stick | TIG | MMA,GOUGING,CELLULSE | TIG | FCAW | ||||||
| No-load voltage (VRD OFF) | 76 | 76 | 76 | 76 | 76 | ||||||
| No-load voltage (VRD ON) | 15 | N/A | 15 | N/A | N/A | ||||||
| Current Range | (30-300A)* 2 | 14-50V | |||||||||
| Welding Current(A) | 235 | 300 | 235 | 300 | 235 | 300 | 235 | 300 | 235 | 300 | |
| Welding Voltage(V) | 29.4 | 32 | 19.4 | 22 | 29.4 | 32 | 19.4 | 22 | 25.8 | 29 | |
| Duty Cycle(%) | 100 | 60 | 100 | 60 | 100 | 60 | 100 | 60 | 100 | 60 | |
| V-A Curve | Drooping | Flat | |||||||||
| Single operation(A or B) | Handle A | Handle B | |||||||||
| Welding Processes | Stick | TIG | Stick | TIG | FCAW | ||||||
| No-load voltage | 76 | 0 | 76 | 0 | |||||||
| Current Range | 30-350A | 30-500A | 14-50V | ||||||||
| Welding Current(A) | 300 | 350 | 300 | 350 | 400 | 500 | 400 | 500 | 400 | 500 | |
| Welding Voltage(V) | 32 | 34 | 22 | 24 | 36 | 40 | 26 | 30 | 34 | 39 | |
| Duty Cycle(%) | 100 | 60 | 100 | 60 | 100 | 60 | 100 | 60 | 100 | 60 | |
| V-A Curve | Drooping | Flat | |||||||||
| GENERATOR | Rated Power | 25kW(Max.27.5kW) | |||||||||
| Excitation Type | AVR Brushless Excitation | ||||||||||
| Frequency | 50Hz/60Hz | ||||||||||
| Phase | Tri-phase | single phase | |||||||||
| AC Output | AC400V/22kW | AC230V/6.9kW | |||||||||
| Model | Yanmar 4TNV98 | Weichai WP2.3D33 | Yuchai 4D24TG | Kubota V3300 (Made in Japan) | Perins 404D-22T | ||||||
| Fuel | Diesel | ||||||||||
| Rated Power | prime 30.7kW( standby 34.1kW) | prime 30kW( standby 33kW) | prime 28kW( standby 30.8kW) | prime 26.9kW( standby 28.9kW) | prime 30kW( standby 32kW) | ||||||
| Rated Speed | 1500r/min | 1800r/min | |||||||||
| Warning Type | Water Temperature /Oil Pressure/Battery charge | ||||||||||
| Cooling Method | Water-cooled | ||||||||||
| WHOLE SET | Fuel Consumption | 6.2L/hr | |||||||||
| Fuel Capacity | 85L | ||||||||||
| Protection Class | IP23 | ||||||||||
| Weight | 760kg | ||||||||||
| Dimension(mm) | 1600*820*1050 | ||||||||||
| Type | multi functional product 3 in 1 | multi functional product 4 in 1 | |||
| Product picture | |||||
| Model | SC200BS | SCD200A | SC200BF-1 | SC200BF-2 | |
| Welding | Load Duration | 60% | 35% | 60% | 60% |
| OCV | DC 75V | DC 75V | DC 75V | DC 75V | |
| Current range(A) | 130/180 | 40A-160A | 50A-200A | 50A-160A | |
| Welding voltage(V) | 22-28V | 22-28V | 22-28V | 22-28V | |
| Welding rod | 1.6-4.0mm | 2.5-3.2 | 1.6-4.0mm | 1.6-4.0mm | |
| Generator | Rated current/voltage(A/V) | 160A/27.2V | 21.6-26.4V | 180A/27.2V | 150A/26V |
| Auxiliary rated power output | 4.5kW | 6kW | 5kW | 7kW | |
| Max.power output | 5kW | 6.5kW | 5.5kW | 7.5KW | |
| Rated frequency | 50Hz/60Hz | 50Hz/60Hz | 50Hz/60Hz | 50Hz/60Hz | |
| Air compressor | Capacity(L) | 17L | / | 2*10L | / |
| Flow | 100L/min | / | 100L/min | / | |
| Pressure range | 0.6-0.8Mpa | / | 0.6-0.8Mpa | / | |
| Engine | Engine model | SC420/CH440 | SV320BA | SC420/CH440 | SC420/CH440 |
| Max.power/speed(RPM) | 8.2kw/3600rpm | 3600rpm | 14HP/3600rpm | 14HP/3600rpm | |
| Displacement(cc) | 420cc/429cc | 322cc | 420cc/429cc | 420cc/429cc | |
| Start method | Recoil/E-start | E-start | Recoil/E-start | Recoil/E-start | |
| Whole set | Fuel tank capacity(L) | 30 | 12.5 | 30 | 30 |
| Protection class | IP21S | IP21S | IP21S | IP21S | |
| Dimension(mm) | 860*600*800 | 770*500*525 | 860*615*930 | 800*620*990 | |
| Net weight(kg) | 120 | 130 | 160 | 158 | |
| Cutting | Current Range(A) | / | 10-40 | / | 10-40 |
| Cutter Plate Thickness(mm) | / | 1-10 | / | 1-10 | |
| Lighting | Lighting(W) | / | / | LED 4X100w | / |
| Lighting height (m) | / | / | 3.5m | / | |
| Type | permanent magnet welding generator | medium frequency welding generator | |||
| Product picture | |||||
| Model | SK130A | AXQ-250 | AXQ-300A | AXQ-300 | |
| Welding | 50% | 50% | 60% | 60% | 60% |
| Load Duration | DC 50V | DC 80V | DC 90V | DC 90V | |
| Current range(A) | 70A/24.8V 130A/25.2V | 50A-240A | 50A-300A | 50A-300A | |
| Welding voltage(V) | 22-29.6V | 22-32V | 22-32V | ||
| Welding rod | 1.6-3.2mm | 1.6-5.0mm | 1.6-6.0mm | 1.6-6.0mm | |
| Generator | Rated current/voltage(A/V) | 120A/24.8V | 230A/29.2V | 280A/31.2V | 280A/31.2V |
| Auxiliary rated power output | 0.8 | DC 2kW | DC 2kW | DC 2kW | |
| Max.power output | 1kW | 2.2kW | 2.2kW | 2.2kW | |
| Rated frequency | 50Hz/60Hz | 50Hz/60Hz | 50Hz/60Hz | 50Hz/60Hz | |
| Engine | Engine model | SC230 | SC460 | GB680 | GB680 |
| Max.power/speed(RPM) | 7.5HP/3600rpm | 16HP/3600rpm | 13.5kW/3600rpm | 13.5kW/3600rpm | |
| Displacement(cc) | 223cc | 459cc | 688cc | 688cc | |
| Start method | Recoil | Recoil/E-start | Recoil/E-start | Recoil/E-start | |
| Whole set | Fuel tank capacity(L) | 15 | 18 | 45 | 18 |
| Protection class | IP21S | IP21S | IP21S | IP21S | |
| Dimension(mm) | 555*480*535 | 780*545*625 | 755*625*850 | 945*625*850 | |
| Net weight(kg) | 32 | 85 | 150 | 122 | |
